5Pcs Black SIP 1A05 Relay Switches 1A NO 4‑Pin Module by Jinshining

Description

Product Overview

The Jinshining 5Pcs Black SIP 1A05 relay set is engineered for dependable performance in demanding industrial and scientific environments. Each relay operates at a nominal 5 V DC supply and supports a continuous current of 1 A, making it suitable for a wide range of low‑power signal switching tasks. The internal reed switch provides a DC resistance between 450 and 550 ohms, ensuring stable contact resistance and predictable behavior over the product’s lifespan. The normally open (NO) contact configuration means the circuit remains open until the relay is energized, offering precise control for applications such as sensor interfacing, indicator lighting, and control logic.

Physically, the relays adopt a compact 4‑pin SIP (Single In‑line Package) footprint measuring just 1 × 1 × 0.2 inches and weighing 1.23 oz, allowing dense placement on printed circuit boards (PCBs). The black housing provides a neutral aesthetic that blends seamlessly with most electronic assemblies while offering protection against electromagnetic interference. The package includes five identical units, giving designers the flexibility to implement multi‑channel switching or maintain spares for future maintenance.

Usage

These relays excel in environments where space is at a premium and reliable switching is essential. Typical use cases include industrial control panels, automation equipment, test and measurement rigs, and hobbyist projects that require precise signal routing. The 5 V operating voltage aligns with common microcontroller platforms such as Arduino, Raspberry Pi, and PLC systems, enabling straightforward integration without the need for additional voltage regulation.

Because the contacts are normally open, the relays are ideal for safety‑critical applications where a circuit must remain inactive until a deliberate command is issued. Examples include emergency stop circuits, interlock systems, and power‑sequencing modules. The low coil current draw also reduces overall power consumption, an important factor in battery‑powered or energy‑efficient designs.

Installation is simplified by the standard 4‑pin layout: two pins for the coil (positive and negative) and two pins for the contact circuit (common and normally open). This configuration allows designers to route power and signal lines cleanly, minimizing cross‑talk and simplifying troubleshooting. The relays can be soldered directly onto a PCB or mounted on a breakout board for prototyping.

Why Choose Us

Jinshining is a recognized manufacturer of high‑quality electronic components, and this relay set reflects the company’s commitment to durability and performance. Each unit undergoes rigorous testing to verify coil resistance, contact resistance, and switching reliability, ensuring that the relays meet or exceed industry standards for industrial switches. The black SIP housing is fabricated from robust materials that resist corrosion and mechanical stress, extending the product’s service life even in harsh operating conditions.

Beyond the hardware, Jinshining provides responsive technical support and a clear warranty policy, giving customers confidence that any issues will be addressed promptly. The inclusion of five relays per package reduces the total cost of ownership by eliminating the need to purchase additional spares separately. Moreover, the product’s compliance with RoHS and other environmental directives assures users that it is safe for use in a variety of regulated markets.

Key Features

• Five black SIP‑1A05 relays provide a compact, space‑saving solution for multi‑channel projects.
• 5 V DC operation with 1 A rating delivers reliable switching while keeping power consumption low.
• 450‑550 Ω contact resistance ensures stable performance and predictable signal behavior.
• Normally open contacts give precise control for safety‑critical and sequencing applications.
• Jinshining’s dedicated support and warranty provide peace of mind and long‑term reliability.

FAQ

What is the maximum switching voltage for these relays?

The relays are rated for a maximum switching voltage of 30 V DC, which covers most low‑power signal applications in industrial and hobbyist projects.

Can the relays be used with AC signals?

While the relays are optimized for DC operation, they can handle AC voltages up to 30 V at low current levels, but users should verify compatibility with their specific circuit requirements.

How do I mount the relays on a PCB?

Simply align the 4‑pin SIP footprint with the corresponding pads on your board and solder each pin. The compact size allows for high‑density placement, and the black housing helps with visual identification during assembly.

Are these relays RoHS compliant?

Yes, the Jinshining SIP‑1A05 relays meet RoHS standards, ensuring they are free from hazardous substances and suitable for environmentally regulated markets.

What warranty does Jinshining offer?

Jinshining provides a one‑year limited warranty covering manufacturing defects, backed by responsive technical support to assist with any installation or performance questions.
